4. STRUCTURAL DESIGN OF LVL STRUCTURES
The calculations are made assuming that the floor is unloaded,
i.e. only the mass of the floor and other permanent actions are
accounted for. Note: in some National Annexes a part of the
live load is also taken into consideration, e.g. in Finland 30 kg/
m
2 31
. For a rectangular floor with span l, the fundamental fre-
quency
f
1
may be approximately calculated as follows:
f_1=π/(2l^2 ) √((EI)_l/m)
(4.78) (EC5 7.5)
where
m
is mass per unit area [kg/m
2
];
l
is the floor span [m]; and
(EI)
l
is the equivalent plate bending stiffness of the floor
about an axis perpendicular to the beam direction
calculated for 1 metre wide section [Nm
2
/m].
For a rectangular floor with overall dimensions b x l, simply
supported along all four edges, the value may, as an approxi-
mation, be taken as:
v=(4 ∙ (0,4 + 0,6 n_40 ))/(m ∙ b ∙ l + 200)
(4.79) (EC5 7.6)
where
v
is the unit impulse velocity response [m/Ns
2
];
n
40
in the number of first-order modes with natural
frequencies up to 40 Hz;
b
is floor width [m];
m
is the mass [kg/m
2
]; and
l
is the floor span [m].
The value of n40 may be calculated from:
n_40={((4
(4.80) (EC5 7.7)
where (EI)b is the equivalent plate bending stiffness of the
floor about an axis parallel to the beam direction calculated for
a 1 metre wide section [Nm
2
/m] and (
EI
)
b
<(
EI
)
l
.
The deflection under
F
=1 kN point load can be calculated
from equations:
w=min{█((F ∙ l^2)/(
(4.81) (EC5 NA, Finland)
31
or
w=(F ∙ l^2)/(43,6 ∙〖 k_(δ )∙ (
(4.82) (EC5 NA, Austria)
33
where
s
is the spacing of the floor beams [m]
k_δ=∜((EI)_b/(EI)_l )
(4.83)
with the limitation
k
δ
≤ b/l
For multiple span floor additional instructions can be
found, e.g., from the National annex of Austria
33
.
For residential floors with a fundamental frequency less
than 8Hz (
f
1
≤ 8Hz) a special investigation should be made.
Instructions for 4,5 Hz ≤
f
1
≤ 8 Hz cases are defined, e.g., in
the National Annexes of Austria
33
or Germany. In practice,
their requirements can be fulfilled only when the own weight
of the floor is >250 kg/m
2
, which is quite heavy for an LVL
floor structure.
4.4 COMBINED CROSS SECTIONS
4.4.1 Basic principles
Glued composite cross sections utilize the joints between
members, significantly increasing the stiffness and resistance
of the whole cross section compared to the members acting
separately. This composite action can be calculated for a me-
chanically jointed cross section, but the influence of joint slip
must then be taken into consideration and, therefore, the over-
all stiffness is much lower. The specific properties of the com-
posite cross section that are essential to the structural analysis –
effective stiffness
EI
eff
, normal stresses from bending moment,
and shear stress at the glued joints – can be defined according
to equations (4.84) – (4.88).
The effective stiffness
EI
eff
of a glued composite cross sec-
tion is calculated according to equation:
〖EI〗_eff= ∑_i▒〖 E_(i ) I_i+E_i A_i e_i^2 〗
(4.84)
