4. STRUCTURAL DESIGN OF LVL STRUCTURES

Table 4.3.

Values of

k

def

for different LVL types in different service classes.

Table 4.2.

Values of k

mod

for LVL (the same values are used for structural timber, glulam and CLT and plywood).

Service class

Permanent

Long-term Medium-term

Short-term Instantaneous

1

0,60

0,70

0,80

0,90

1,10

2

0,60

0,70

0,80

0,90

1,10

3

0,50

0,55

0,65

0,70

0,90

LVL 04, Table 4.3

Product type

Service class 1

Service class 2

Service class 3

LVL-P

0,60

0,80

2,00

LVL-C in edgewise loading

0,60

0,80

2,00

LVL-C in flatwise loading

0,80

1,00

2,50

u

fin

=

u

inst,G

(1+

k

def

) +

u

inst,Q,1

(1+

ψ

2,1

k

def

) +

u

inst,Q,i

(

ψ

0,i

+

ψ

2,i

k

def

)

(4.2)

where

u

fin

is the final deflection including creep deformation;

u

inst,G

is the instantaneous deflection due to permanent

actions;

u

inst,Q,1

is the instantaneous deflection due to the leading

variable action; and

u

inst,Q,i

is the instantaneous deflection due to accompanying

variable actions.

LVL-C has a higher

k

def

value when the loading causes defor-

mation in the flatwise direction due to rolling shear deforma-

tion of the cross veneers similar to plywood. When LVL-C pan-

el is used as a component of stressed-skin panels, the

k

def

value

in the longitudinal direction of the element is the same as for

LVL-P, because the loading causes mainly axial stresses on the

panel.

4.1.6 Design resistance and stiffness

Design resistance in ULS design is determined from the design

values of the strength properties by modifying the character-

istic properties with partial safety factor

γ

M

and modification

factor

k

mod

.

f_d=(k_mod∙f_k)/γ_M

(4.3) (EC5 2.17)

where

f

k

is the characteristic 5% value of a strength property;

k

mod

is the modification factor that takes into account the

duration of load and service class, see Table 4.2; and

γ

M

is the partial safety factor of the material.

Mean values for stiffness properties are used in SLS design

and are determined for short-term loading in service class 1

conditions. The influence of creep deformation is taken into

account by the

k

def

factor. Characteristic 5% stiffness values are

used for stability calculation in ULS design.

4.2 STRUCTURAL PROPERTIES OF LVL

AND STRENGTH CLASSES

The mechanical properties of structural LVL are determined

according to the harmonized product standard EN 14374. The

properties are assessed and their constancy of performance

verified according to the AVPC system 1 of the EU construc-

tion product regulations. LVL suppliers declare their individ-

ual product properties in their Declaration of Performance

(DoPs).

In the future EN 14374 LVL product categories will be

introduced but in the meanwhile LVL industry has decided

to launch them as LVL strength classes. Information about

the strength classes can be found from the Laminated Veneer

Lumber (LVL) bulletin: New European strength classes

15

,

FprEN 14374 Annex B, and these are described in the following

subsections 4.2.1 and 4.2.2.

The bending and axial strength and stiffness properties of

LVL-C with crossband veneers having different layups (i.e. ve-

neer orientation) may be calculated from one set of tests ac-

cording to FprEN 14374 Annex A by applying layup factors

according to Annex C for thickness ranges specified in Annex

A. LVL-C properties are defined with the assumption that the

cross veneers are zero layers.

fin

=

inst,G

(1 +

def

) +

inst,Q,1

�1 +

2,1

def

� +

inst,Q,i

0,i

+

2,i

def

(4.2)

d

=

mod

k M

(4.3) (EC5 2.17)

(4.2)

fin

=

inst,G

(1 +

def

) +

inst,Q,1

�1 +

2,1

def

� +

inst,Q,i

0,i

+

2,i

def

(4.2)

d

=

mod

k M

(4.3) (EC5 2.17)
