9. CALCULATION EXAMPLES OF LVL STRUCTURES
K_ser=〖ρ_k〗^1,5∙d^0,8/30=454 N/mm
γ=1/(1+(π^2∙E_0∙h_0 〖∙b〗_0∙s_0)/(K_ser∙〖L_0〗^2 ))=1/(1+(π^2∙7000 N/mm^2∙22 mm∙100 mm∙200 mm)/
(454N/mm∙(5000 mm)^2 ))
γ
= 0,27
(EI)_bracing=2∙2∙7000N/mm^2 ∙((100 mm∙(22 mm)^3/12+0,27∙100 mm∙2)
(EI)_bracing=6,44∙〖10〗^4 Nm^2/m
The stiffness of the 45x45 mm cross battens C14 solid wood underneath the floor:
(EI)_(cross battens)=7000 N/mm^2 ∙(1000 mm)/(400 mm)∙(45 mm ∙(45 mm)^2)/12=5,98∙〖10〗^3 Nm^2/m
〖(EI)〗_b= 〖(EI)〗_decking + 〖(EI)〗_bracings + 〖(EI)〗_(cross battens)
〖(EI)〗_b = 3,11∙〖10〗^3 Nm^2/m + 6,44∙〖10〗^4 Nm^2/m + 5,98∙〖10〗^3 Nm^2/m
〖(EI)〗_b = 7,35∙〖10〗^4 Nm^2/m
k_(δ,2)=∜((EI)_b/(EI)_l =) ∜((6,44∙〖10〗^4)/(1,79∙〖10〗^6 ))=0,45
w_2=min{█((1kN∙(4,5m)^2)/█(42∙0,45∙1,79∙(〖10〗^6 Nm^2)/m@ )@(1kN∙(4,5m)^3)/(48∙0,4∙1,79∙(〖10〗^6
Nm^2)/m))┤=min{█(0,6 mm@ @2,7 mm)┤=0,6 mm→OK
The transfer bracing lines and cross battens underneath the joists improve the floor stiffness under a 1kN
point load significantly and the vibration design requirements are fulfilled. The deflection could be decreased
~0,2 mm more, by gluing the decking onto the joists.
